LED Sphere

The Display That Turns Heads from Every Angle.

Quick specs

  • Variant 1 Model: LED Sphere P2.5 (Large)
  • Variant 2 Model: LED Sphere P2.5 (Medium)
  • Variant 3 Model: LED Sphere P1.9 (Small)
LED

Overview

LED Sphere Display for 360° Visuals Without Dead Zones

Traditional flat displays can have limited visibility when used on center stages or open exhibition booths. LED Sphere provides a spherical display surface that can be viewed from multiple directions, making it suitable for stage installations, exhibitions, and branded environments. Using standard projection arrays on curved surfaces can also result in faded images due to venue ambient lights or shadow interference.

Its spherical form allows content to face multiple directions, helping logos, product animations, and visual campaigns remain visible across open layouts. This distinct design makes the unit suitable as a visual centerpiece, encouraging attendees to stop, watch, and capture photos of the display area.

Diameter & Pixel Pitch Options:
The product range offers custom digital configurations. It is available in three sizes: a 40 cm diameter with a P1.9 pixel pitch for close-up viewing, and 1.0 metre and 1.5 metre diameters with a P2.5 pixel pitch for larger spatial configurations.

To support use in short-term events or long-term installations, all variants use sheet-metal cabinets with a sandblasted iron-box construction to protect internal components. Each module has a resolution of 128 × 64, while the listed power consumption is 750–800 W/m².

Note: 128 × 64 is the module resolution, not the total resolution of the LED Sphere. The total resolution depends on the module configuration for each unit size.

Examples of Size Selection for LED Sphere

Choose the proper structural sizing based on your specific venue requirements and layout parameters:

  • 40 cm: suitable for booths, counters, podiums, or close-up product displays.
  • 1 metre: suitable for ballrooms, foyers, medium stages, or branding installations.
  • 1.5 metres: suitable for large stages, atriums, or areas requiring a more dominant centerpiece presence.

Final recommendations depend on venue dimensions, viewing distance, lighting, mounting positions, and the event's visual concept.

Application Recommendation Matrix

Event / Venue Requirements Recommended Dimensions Technical Variant
Booths, Counters, Retail Windows, Logo Branding 40 cm P1.9 Variant (Small)
Ballrooms, Standard Staging, Corporate Hotels 1.0 Meter P2.5 Variant (Medium)
Music Concerts, Open Spaces, Large Arenas 1.5 Meter P2.5 Variant (Large)

Use Cases

  • Main Stage Visual Centerpiece
    The 1.0m or 1.5m sphere models serve as a central display on the stage setup, delivering consistent visual playback to the audience from multiple angles.
  • Exhibition Booth Branding
    Positions the 40cm or 1.0m systems on display platforms inside expo zones to show corporate logos, attracting foot traffic from multiple aisles.
  • Indoor Architectural Media Features
    Deploys as a digital display asset inside television studios, halls, or commercial spaces to complement flat screen matrices.

[TECHNICAL SPECIFICATIONS]

Available Variants: LED Sphere P2.5 (Large) / LED Sphere P2.5 (Medium) / LED Sphere P1.9 (Small)
Variant 1 Model: LED Sphere P2.5 (Large)
Variant 1 Diameter: 1.5 Meters
Variant 1 Pixel Pitch: P2.5
Variant 1 Module Resolution: 128 × 64
Variant 1 Cabinet Material: Sheet metal, sandblasted iron box
Variant 1 Power Consumption: 750 – 800W/m²
Variant 1 Output Pixel: 1880 (W) × 980 (H)
Variant 1 Product Height: 200 cm
Variant 1 Input Resolution Content: 16:9
Variant 2 Model: LED Sphere P2.5 (Medium)
Variant 2 Diameter: 1.0 Meter
Variant 2 Pixel Pitch: P2.5
Variant 2 Module Resolution: 128 × 64
Variant 2 Cabinet Material: Sheet metal, sandblasted iron box
Variant 2 Power Consumption: 750 – 800W/m²
Variant 2 Output Pixel: 1416 (W) x 604 (H)
Variant 2 Product Height: 125 cm
Variant 2 Input Resolution Content: 16:9
Variant 3 Model: LED Sphere P1.9 (Small)
Variant 3 Diameter: 40 cm
Variant 3 Pixel Pitch: P1.9
Variant 3 Module Resolution: 128 × 64
Variant 3 Cabinet Material: Sheet metal, sandblasted iron box
Variant 3 Power Consumption: 750 – 800W/m²
Variant 3 Output Pixel: 620 (W) x 282 (H)
Variant 3 Product Height: 50 cm
Variant 3 Input Resolution Content: 16:9

FAQ

  • Q: What are the exact diameter options manufactured for the LED Sphere lineup?
    • A: The system is built in three technical sizes: 40 cm, 1.0 metre, and 1.5 metres.
  • Q: Is the cabinet structure robust enough to support this display?
    • A: All variants use sheet-metal cabinets with a sandblasted iron-box construction to maintain shape stability and protect internal components. On-site installation feasibility depends on unit inspection and local mounting methods.
  • Q: What are the module resolution and operational power specifications?
    • A: Every model variant runs on a native 128 × 64 module resolution profile, operating on a power draw matrix of 750 – 800W/m².
  • Q: Which option provides the most optimal pixel density for close-up viewing?
    • A: The compact 40 cm diameter model operates on a P1.9 pixel pitch layout for close-up visual clarity.
